ComAp InteliLite MRS16 User Manual

InteliLite Global Guide
159
Setpoint group Basic settings Related FW 1.2.1
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 11657 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type (page 157).
Description
Nominal system (generator) voltage (phase to phase).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-Ph 1 (page
292) and Nominal Voltage Ph-Ph 2 (page 294).
Nominal Voltage Ph-Ph
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 0,1 .. 500,0 [V/V]
Default value 1,0 V/V Alternative config NO
Step 0,1 V/V
Comm object 9579 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Generator voltage potential transformers ratio. If no PTs are used, adjust the setpoint to 1.
PT Ratio
6 back to List of setpoints
Subgroup: Frequency settings
Setpoint group Basic settings Related FW 1.2.1
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 8278 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Nominal system (generator) frequency (usually 50 or 60Hz).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Frequency 1 (page 291)
and Nominal Frequency 2 (page 293).
Nominal Frequency
6 back to List of setpoints
