InteliLite Global Guide
293
Setpoint group Basic settings Related FW 1.2.1
Range [units] Monophase / Splitphase / 3Ph3Wire / High Leg D / 3Ph4Wire / Autodetect [-]
Default value 3Ph4Wire Alternative config YES
Step [-]
Comm object 12059 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Connection type (page 157)
has the same value as setpoint Connection type 2. Setpoint Connection type (page 157) can be changed
from both places - from Basic settings setpoint group and from Alternate Config setpoint group.
Connection type 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 1 .. 10 000 [A]
Default value 350 A Alternative config YES
Step 1 A
Comm object 12050 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type 2 (page 293).
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Nominal Current (page 156)
has the same value as setpoint Nominal Current 2. Setpoint Nominal Current (page 156) can be changed
from both places - from Basic settings setpoint group and from Alternate Config setpoint group.
Nominal Current 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 9914 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Nominal Frequency (page
159) has the same value as setpoint Nominal Frequency 2. Setpoint Nominal Frequency (page 159) can be
changed from both places - from Basic settings setpoint group and from Alternate Config setpoint group.
Nominal Frequency 2
6 back to List of setpoints
