Page #161 background imageLoading...
Page #161 background image
InteliMains 210 Global Guide
161
7 Technical data
Power supply range
8-36 V DC
Power consumption
320 mA / 8 V DC
210 mA / 12 V DC
120 mA / 24 V DC
90 mA / 36 V DC
RTC battery
Replaceable
Fusing
Power terminal max. 4 A
w/o BOUT consumption
E-Stop max.12 A
Fusing E-Stop
12 A
Max. Power
Dissipation
9 W
Power supply
Max. excitation current
250 mA
Charging fail threshold
80 % of Usupply
D+
Operating
temperature
-20 ËšC to +70 ËšC
Operating
temperature for Low
Temp. version
-40 ËšC to +70 ËšC
Storage temperature
-30 ËšC to +80 ËšC
Protection degree
(front panel)
IP 65
Operating humidity
95 % w/o condensation
Vibration
5-25 Hz, ± 1,6 mm
25-100 Hz, a = 4 g
Shocks
a = 500 m/s
2
Surrounding air temperature rating 70°C
Suitable for pollution degree 2
Operating conditions
Measurement
inputs
3ph-n Gen voltage , 3ph-n Mains
Measurement
range
277 V ph-n
Max. allowed
voltage
350 V ph-n
Accuracy
1 %
Frequency
range
40-70 Hz (accuracy 0.1 Hz)
Input
impedance
0,72 MΩ ph-ph , 0,36 MΩ ph-n
Voltage measurement
Type
Build-in monochromatic 3,2"
Resolution
132 x 64 px
Display
Number
8, non-isolated
Close/Open
indication
0-2 V DC close contact
6-36 V DC open contact
Binary inputs
Low
current
6 low current output, non-isolated
BO 3-8 = 0,5 A
switching to positive supply terminal
Binary outputs
USB port
Non-isolated
CAN 1 + CAN 2
250 / 50 kbps, isolated,
nominal impedance 120 Ω
Communications
6 back to Table of contents
