ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
25
4.4 Recommended wiring
Current inputs 29 - 32 Current measurement wiring (page 28)
Mains voltage inputs 37 - 40 Voltage measurement wiring (page 30)
Bus voltage inputs 41 - 44 Voltage measurement wiring (page 30)
Binary inputs 45 - 52 Binary inputs (page 33)
CAN1 H, COM, L CAN bus and RS485 wiring (page 34)
CAN2 H, COM, L CAN bus and RS485 wiring (page 34)
Binary outputs 07 - 12 Binary Outputs (page 34)
Power supply "+" D "-" Power supply (page 26)
RS485 A, COM, B CAN bus and RS485 wiring (page 34)
USB USB B USB (page 39)
USB HOST USB A USB HOST (page 39)

ComAp InteliMains 210 BTB Specifications

General

Brand	ComAp
Model	InteliMains 210 BTB
Category	Controller
Language	English
