8.1.2 Values
What values are:
Values (or quantities) are analog or binary data objects, measured or computed by the controller, that are
intended for reading from the controller screen, PC, MODBUS, etc. Values are organized into groups according
to their meaning.
Invalid flag
If valid data is not available for a particular value, the invalid flag is set to it. This situation may be due to the
following:
The value is not being evaluated in the scope of the current application and configuration.
Sensor fail has been detected on an analog input.
The communication with extension module is interrupted.
A value containing the invalid flag is displayed as “####” in InteliConfig and on the controller screen. If such a
value is read out via MODBUS, it will contain the data 32768 in the case of signed values and 65535 in the case
of unsigned values.
List of values groups
Group: Bus Left 367
Group: Power Management 374
Group: Load Control 377
Group: Voltage/PF Control 378
Group: Controler I/O 378
Group: Statistics 379
Group: Info 380
Group: Log Bout 384
Group: CM-GPRS 386
Group: CM-Ethernet 391
Group: Date/Time 394
Group: Plug-In I/O 394
Group: PLC 395
For full list of setpoints go to the chapter List of values (page 365).
