8.1.1 Setpoints
What setpoints are:
Setpoints are analog, binary or special data objects which are used for adjusting the controller to the specific
environment. Setpoints are organized into groups according to their meaning. Setpoints can be adjusted from
the controller front panel, PC, MODBUS, etc.
All setpoints can be protected by a password against unauthorized changes. Password protection can be
assigned to the setpoints during the configuration procedure.
IMPORTANT: Do not write setpoints repeatedly (e.g. power control from a PLC by repeated writing
of baseload setpoint via Modbus). The setpoints are stored in EEPROM memory, which can be
overwritten up to 10
5
times without risk of damage or data loss, but it may become damaged, when
the allowed number of writing cycles is exceeded.
List of setpoint groups
Group: Process Control 170
Group: Basic settings 175
Group: Communication Settings 181
Group: Bus Right Settings 182
Group: Bus Left Settings 185
Group: Power Management 192
Group: Load Control 202
Group: Voltage/PF Control 203
Group: Synchronisation 204
Group: General Analog Inputs 207
Group: Scheduler 247
Group: Plug-In Modules 262
Group: CM-RS232-485 263
Group: CM-GPRS 265
Group: CM-4G-GPS 274
Group: CM-Ethernet 284
Group: Alternate Configuration 294
Group: PLC 300
For full list of setpoints go to the chapter List of setpoints (page 165).
