InteliMains 210 Global Guide
294
Setpoint group
CM-GPRS; CM-4G-
GPS; CM-Ethernet
Related FW 2.0.0
Range [units] 0 .. 65 535[-]
Default value 23 Alternative config NO
Step [-]
Comm object 24374 Related applications MCB, MGCB, BTB
Description
This setpoint is used to adjust the port number, which is used for Ethernet connection to a PC with any of
ComAp PC program (i.e. InteliConfig). This setpoint should be adjusted to 23, which is the default port used
by all ComAp PC programs. A different value should be used only in special situations as e.g. sharing one
public IP address among many controllers or to overcome a firewall restrictions.
IMPORTANT: If AirGate is used, this setpoint has to be adjusted to 23.
Note: This setpoint is common for CM-Ethernet, CM-GPRS and CM-4G-GPS modules.
ComAp TCP Port
6 back to List of setpoints
Group: Alternate Configuration
Subgroup: Configuration 1
Setpoint group Basic settings Related FW 2.0.0
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 9913 Related applications MCB, MGCB, BTB
Description
Nominal system frequency (usually 50 or 60 Hz).
Note: This value is used when any other alternate configuration is not active.
Nominal Frequency 1
6 back to List of setpoints
Setpoint group Basic settings Related FW 2.0.0
Range [units] 80 .. 20000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 12052 Related applications MCB, MGCB, BTB
Description
Nominal system voltage (phase to neutral).
Note: This value is used when any other alternate configuration is not active.
Nominal Voltage Ph-N 1
6 back to List of setpoints
