Setpoint group Load Control Related FW 2.0.0
Range [units] 0,0 .. 200,0 [%]
Default value 10,0 % Alternative config NO
Step 0,1 %
Comm object 8718 Related applications MCB, MGCB, BTB
Description
This setpoint is used for adjusting of the gain factor (P-factor) of the phase angle P-control loop.
Note: During synchronization, first the frequency loop is started to match the generator frequency with
the mains or bus and after that the phase angle loop is started to match the phase angle.
Note: See the chapter Regulation loops (page 100) for more information.
Angle Gain
6 back to List of setpoints
Group: Voltage/PF Control
Subgroup: Regulation Loops
Setpoint group Voltage/PF Control Related FW 2.0.0
Range [units] 0,0 .. 200,0 [%]
Default value 10,0 % Alternative config NO
Step 0,1 %
Comm object 8501 Related applications MCB, MGCB, BTB
Description
This setpoint adjusts the gain factor (P-factor) of the voltage control PI loop.
Note: See the chapter Regulation loops (page 100) for more information.
Voltage Gain
6 back to List of setpoints
Setpoint group Voltage/PF Control Related FW 2.0.0
Range [units] 0 .. 100 [%]
Default value 50 % Alternative config NO
Step 1 %
Comm object 8720 Related applications MCB, MGCB, BTB
Description
This setpoint adjusts the relative integration factor (I-factor) of the voltage control PI loop.
Note: See the chapter Regulation loops (page 100) for more information.
Voltage Int
6 back to List of setpoints
