ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
233
General Analog Input 14
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9298 Related applications MCB, MGCB, BTB
Description
Warning or history threshold level for AIN PROT14 (PAGE 477).
Note: These setpoints are used only if LAI AIN PROT14 (PAGE 477) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 14 Wrn
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9299 Related applications MCB, MGCB, BTB
Description
Shutdown or BOC threshold level for AIN PROT14 (PAGE 477).
Note: These setpoints are used only if LAI AIN PROT14 (PAGE 477) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 14 Sd
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] 0 .. 900 [s]
Default value 0 s Alternative config NO
Step 1 s
Comm object 9300 Related applications MCB, MGCB, BTB
Description
Delay for AIN PROT14 (PAGE 477).
Note: These setpoints are used only if LAI AIN PROT14 (PAGE 477) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 14 Delay
6 back to List of setpoints
