InteliMains 210 Global Guide
239
General Analog Input 17
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9307 Related applications MCB, MGCB, BTB
Description
Warning or history threshold level for AIN PROT17 (PAGE 480).
Note: These setpoints are used only if LAI AIN PROT17 (PAGE 480) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 17 Wrn
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9308 Related applications MCB, MGCB, BTB
Description
Shutdown or BOC threshold level for AIN PROT17 (PAGE 480).
Note: These setpoints are used only if LAI AIN PROT17 (PAGE 480) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 17 Sd
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] 0 .. 900 [s]
Default value 0 s Alternative config NO
Step 1 s
Comm object 9309 Related applications MCB, MGCB, BTB
Description
Delay for AIN PROT17 (PAGE 480).
Note: These setpoints are used only if LAI AIN PROT17 (PAGE 480) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 17 Delay
6 back to List of setpoints
