InteliMains 210 Global Guide
482
Related FW 2.0.0 Related applications MCB, MGCB, BTB
Comm object 9981
Description
Logical analog input designed for general value received from analog sensor. Limits for this protection are
adjusted by setpoints Analog Protection 19 Wrn (page 243) and Analog Protection 19 Sd (page 243). Delay is
adjusted by setpoint Analog Protection 19 Delay (page 243).
Monitoring Analog value is only measured and displayed on the LCD screen but not used for
protection.
HistRecOnl Analog value is only measured and displayed on the LCD screen but not used for
protection. History record is made if value is out of the limits.
AL Indic Analog value is not used for protection. Only alarmlist record is made if analog
value is out of the limits.
Wrn Analog value is used for warning protection only.
Wrn+Stp Analog value is used for warning and slow stop protection
Stp Analog value is used for slow stop protection
Wrn+BOR Analog value is used for warning and breaker open protection
BOR Analog value is used for breaker open protection
Protection types
Note: This parameter has to be adjusted via InteliConfig.
Under limit Alarm is activated when value of analog input is under adjusted limits
Over limit Alarm is activated when value of analog input is over adjusted limits
Under limit + fls Alarm is activated when value of analog input is under adjusted limits. If sensor fail
is detected then the alarm with higher level is activate as well.
Over limit + fls Alarm is activated when value of analog input is over adjusted limits. If sensor fail
is detected then the alarm with higher level is activate as well.
Alarm
Example: Protection type is Wrn + Sd. When sensor fail is detected then Sd alarm will be activated +
Sensor fail alarm will be activated.
Note: This parameter has to be adjusted via InteliConfig.
AIN Prot19
6 back to Logical analog inputs alphabetically
