InteliMains 210 Global Guide
498
Image 8.148 Principle of delay
Image 8.149 Configuration of Comp Time block
Note: Input 2 and Delay can be constants or values from controller.
6 back to List of PLC blocks
Group: Time functions
PLC group Time functions
Related FW 2.0.0
Related applications AMF, MRS MINT, SPtM
Comm object 14
Inputs
Input Type Negation Range Function
Run Binary No 0/1
The timer runs only if this input is
active or not connected
Reload Binary No 0/1
This input reloads the timer to the
initial value
Reload
value
Analog No 0,0..3276,7 [s] Initial value of the timer
Outputs
Timer
