InteliMains 210 Global Guide
547
Image 8.165 CM-4G-GPS module
IMPORTANT: Any manipulation with plug-in module shall be done with disconnected power
supply to controller.
IMPORTANT: CM-4G-GPS and CM-GPRS modules cant be used in one controller in the same time.
IMPORTANT: Operating temperature of module is from -30°C to +75°C.
Note: Cellular data service must be enabled in your SIM card by your mobile operator for successful operation.
CM-4G-GPS module works with:
WebSupervisor – internet-based remote monitoring solution
AirGate – powerful connection technology to make internet access as simple as possible
Locate – Celluar network based localization service
CM-4G-GPS module also works like GPS locator. Geo-fencing function can be used with this module.
Supported 4G bands are as follows:
FDD LTE: Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 20, all bands with diversity
WCDMA/HSDPA/HSUPA/HSPA+: Band 1, Band 2, Band 5, Band 8, all bands with diversity
GSM/GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/1900 MHz
Power consumption
55 mA / 8 VDC
35 mA / 12 VDC
8 mA / 24 VDC
5 mA / 36 VDC
Technical data
SIM card settings
SIMcard to be used in CM-4G-GPS or CM-GPRS modules must be adjusted as follows:
SMS service enabled
Packet data (Internet access) enabled (when required for the selected mode of operation)
PIN code security disabled
How to start using CM-4G-GPS module
You will need a controller, CM-4G-GPS module, antenna and SIM card with SMS and packet data service.
