InteliMains 210 Global Guide
560
Accuracy: ± 0,25 % of actual value + ± 50 µA
Resistive
Range: 0- 10 kΩ
Accuracy: ± 0,5 % of actual value + ± 2 Ω
Inteli IO8/8
Inteli IO8/8 module is an extension module equipped with binary inputs, binary outputs and analog outputs.
Inteli IO8/8 is the name of the module, but it is possible to configure the module (by internal switch) to two
configurations:
Inteli IO8/8 - 8 binary inputs, 8 binary outputs and 2 analog outputs
Inteli IO16/0 - 16 binary inputs, 0 binary outputs and 2 analog outputs
The detection of communication speed is indicated by fast flashing of status LED. Once the speed is detected
the module remains set for the speed even when the communication is lost. Renewal of communication speed
detection is done by reset of the module.
Image 8.173 Inteli IO8/8
