Other features
User buttons
The user has possibility to assign various functions of SoftKeys buttons - buttons on the bottom of
Intelivision 5 (see Chyba! Nenalezen zdroj odkazů.). Different functions can be assigned to any
button of any screen.
Pre-defined functions
• Fast jump to any Measurement & Setpoints screen
• Binary signal activation
o Set button - each press of a button sets binary signal to 1
o Reset button - each press of a button sets binary signal to 0
o Toggle button - 1. press set binary signal to 1 or 0 and next press set value to
opposite value. Initial value can be defined.
o Pulse generator (the button generates pulse 1)
• Genset commands (start, stop, MCB on, faultReset etc. )
See example in figure below. The first button is fast link to “Generator protection” list in Setpoints
Menu and the second button is fast link to “Statictic I.” screen in Measurement. Labels on buttons are
customizable.
The functions can be easily defined in a new graphical Screen editor. Functions actually assigned to
buttons in actual archives are default.
Support of the internal buzzer (IV5-RD)
InteVision 5-RD contains an internal buzzer. New parameter “Internal Horn” relating to the internal
buzzer was implemented.
Parameter enables/disables using of internal buzzer. The parameter is placed in “IV setting” MENU
and it is available only in IV5-RD display. Default setting is enabled.
InteliVision 5-1.1 Reference Guide ©ComAp – December 2011 35
