List of Possible Events
InteliVision 5 screen texts Description
Detecting Controller detection sequence is in progress. Text disappears
when controller is detected.
Checking Controller configuration sequence is checking. Text disappears
when controller is detected.
Reading cfg. Table Controller configuration reading is in progress. Text disappears
when controller is detected.
Preparing Display setting Ok.
Running Indication of running display.
Wrong Display HW SW and HW mismatch. Correct firmware has to be programmed.
Invalidate configuration table Error Configuration table is invalid. Controller configuration has to be
reprogrammed or upgraded.
Unsupported controller Error Controller is not supported.
Unsupported cfg. table format Error Controller configuration table is not supported. InteliVision 5
firmware upgrade is necessary.
Mismatch parameters length Error Controller parameters mismatch. Controller configuration
upgrade is necessary.
Mismatch const values length Error Controller constants mismatch. Controller configuration upgrade
is necessary.
Mismatch values length Error Controller values mismatch. Controller configuration upgrade is
necessary.
Mismatch val states length Error Controller values states mismatch. Controller configuration
upgrade is necessary.
Controller was not detected Error Controller is not connected or communication via RS485 is
interrupted. Communication is lost or RS485 line A and B are
swapped.
Communication Error Controller is detected; RS485 communication level is not
defined correctly. Reason of this behaviour could be: RS485 line
is not terminated properly, environment disturbance is present or
RS485 line is too long.
Screen template missing Error Unsupported controller firmware, missing InteliVision 5 support.
Screen template version Error Unsupported controller screen. InteliVision 5 firmware has to be
updated.
Font not valid Error Corrupted display font. Font programming was not done
properly. Display firmware/font programming is necessary.
Font format not supported Error Unsupported font, InteliVision 5 font or firmware is necessary.
Bitmaps not valid Error Bitmaps (generator, engine, fuel and etc...) Firmware upgrade is
necessary.
Bitmaps format not supported Error Unsupported bitmaps format. (Engine, gen-set and etc...)
Firmware upgrade is necessary.
Default lang. not supported Error Default/Defined language error/not supported. Language
change or code page change is necessary.
