41RFU100 – Optical smoke detector with isolator
17/06/2020 14:06
41RFU100
Name
Address
Loop Number
Device Zone
5
2
1
EnabledNormalDevice State
Remove
More
OFF
17/06/2020 14:06
CheckSmoke [%] / Temperature [°C]
ONLed Blink
Device Group
OFFDay Alarm Level
Night Alarm Level
1.1Software Revision
3271557136ID
No RI Out 0
OFF
The figure shows the settings screen for addressed detector 41RFU100.
Press “MORE” to access additional settings:
• Smoke [%] / Temperature [°C]: press “Check” to access the parameter viewing screen:
◊ Smoke: shows the percentage of the current level of smoke in the optical chamber of the detector.
◊ Sensor contamination level: shows the percentage of the current level of contamination in the optical chamber of the
detector.
• LED Blink: select ON/OFF to enable/disable LED indications for the device.
• Device Group: setting for linking a detector to a detector group. Enter a group number (>0) in the editable field; the
detector in question will be assigned to that specific group. This enables the button allowing that detector to activate any
remote light Art. 48FPT100 connected to any detector belonging to the SAME group.
• Day Alarm level*: setting for the sensitivity level in Day mode.
• Night Alarm level*: setting for the sensitivity level in Night mode.
* Note: there are 4 levels for setting the alarm sensitivity level: High, Normal, Middle and Low. To change the sensitivity level,
press the active button next to the field and choose a new level from the list.
* Note: in normal panel operating conditions, an asterisk appears next to the Alarm Level to identify the current operating mode
(day / night) of the fire panel (this can be changed via the maintenance menu).
To save any new parameters, press “Save” on the main device screen.
30
