Ruckus ICX 7450 Switch Hardware Installation Guide 11
Part Number: 53-1003899-09
Ruckus ICX 7450 Overview
• Ruckus ICX 7450 features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Views of the Ruckus ICX 7450 switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Ruckus ICX 7450 slot and Ethernet port numbering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
• Supported expansion modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
• Supported transceivers and cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Ruckus ICX 7450 features
The Ruckus ICX 7450 is a high-density aggregation switch that offers 10/100 Mbps Ethernet, 1/10 Gigabit Ethernet (GbE), and 10/40
GbE line rates, and up to 336 Gbps throughput for campus LAN and classic Ethernet data center environments.
The Ruckus ICX 7450 switch features:
• Comprehensive support for a range of 1 GbE, 10 GbE, and 40 GbE optics (refer to the latest Ruckus Optics Family Data Sheet)
• Dual redundant, hot-swappable power supplies available with intake or exhaust airflow
(250 W AC or 510 W DC for non-PoE switches, and 1000 W AC or 510 W DC for PoE switches)
• ICX 7450-24P and ICX 7450-48P copper ports support PoE, PoE+, High PoE, and PoH
• ICX 7450-48F SFP ports support 1 GbE transceivers
• ICX 7450-32ZP copper ports support PoE, PoE+, High PoE, and PoH
• 1 GbE SFP module with four 10M/100M/1 GbE SFP ports
• 10 GbE SFP+ module with four 1/10 GbE SFP+ ports
• 10 GbE copper module with four 1/10 GbE RJ-45 ports
• Two 40 GbE QSFP+ or four 10 GbE SFP+ stacking ports (supporting stacking for up to twelve switches)
• Dual redundant, hot-swappable fan trays available with intake or exhaust airflow
•
One Gigabit Ethernet port (RJ-45) and one serial management port (mini-USB) to configure and manage the switch through the CLI
• One USB port for the transfer of software and configuration files from an external disk drive
Ruckus ICX 7450 customizable switches
The Ruckus ICX 7450 base systems do not ship with power supplies, fans, stacking modules, or media expansion modules. Fans, power
supplies, and expansion modules are ordered separately to allow for building the system that meets your network needs. Table 3 lists the
available power supplies, fans, and expansion modules.
TABLE 3 SKUs for creating custom Ruckus ICX 7450 switches
Part Description
ICX7400-4X1GF Ruckus ICX 7450 4-port 10M/100M/1 Gbe SFP expansion module
ICX7400-4X10GF Ruckus ICX 7450 4-port 1/10 GbE SFP+ uplink / stacking expansion module
(stacking is available only when the module is installed in slot 2)
ICX7400-4X10GC Ruckus ICX 7450 4-port 1/10 GbE copper expansion module
ICX7400-1X40GQ Ruckus ICX 7450 1-port 40 GbE QSFP+ data uplink / stacking module
(stacking is available only when the module is installed in slot 3 or 4)
