78 Ruckus ICX 7450 Switch Hardware Installation Guide
Part Number: 53-1003899-09
Ruckus ICX 7450 Specifications
Power supply specifications (per PSU)
Power supply specifications (per PSU)
Power consumption (typical configuration)
All 1 G and two 10 G ports are linked up (no other port links), loading with 10 percent traffic rate and no PoE load. 2 fan FRUs, 4x10GC
uplink, and no stacking module. Fans at nominal speed.
ICX7450-32ZP: 24 1-Gig+8 2.5-Gig and Slot1: Empty, Slot2: 4x10GF, Slot3: 4x10GF ports are linked UP, loading with 10% traffic
rate. Two Fans at nominal speed.
Operating noise ICX 7450-24: 46 dBA
ICX 7450-24P: 49 dBA
ICX 7450-32ZP: 47 dBA
ICX 7450-48: 47 dBA
ICX 7450-48P: 49 dBA
ICX 7450-48F: 46 dBA
N/A
MTBF @ 25°C ICX 7450-24: 399,973 Hours
ICX 7450-24P: 317,719 Hours
ICX 7450-32ZP: 568,376 Hours
ICX 7450-48: 376,635 Hours
ICX 7450-48P: 297,862 Hours
ICX 7450-48F: 330,154 Hours
N/A
Power supply
model
Maximum
output power
rating (DC)
Input voltage Input line
frequency
Maximum
input current
Input line
protection
Maximum
inrush
current
AC RPS15-E 250 W 100-240V~ 50-60Hz 4.0A Fuses 35A
AC RPS15-I 250 W 100-240V~ 50-60Hz 4.0A Fuses 35A
AC RPS16-E 1000 W 100-240V~ 50-60Hz 11.8A Fuses 35A
AC RPS16-I 1000 W 100-240V~ 50-60Hz 11.8A Fuses 35A
DC RPS16DC-E 510 W 40-72V - 15.5A Fuses 40A
DC RPS16DC-I 510 W 40-72V - 15.5A Fuses 40A
Model name
(Input power ±5%)
@100 VAC Input @200 VAC Input @-48VDC Minimum number
of power supplies
Notes
ICX 7450-24 88.5 W
302 BTU/hr
87.6 W
299 BTU/hr
80.6W
276 BTU/hr
1 x 250 W AC
1 x 510 W DC
1 PSU
100.1 W
342 BTU/hr
99.2 W
339 BTU/hr
85.3W
291 BTU/hr
1 x 250 W AC
1 x 510 W DC
2 PSUs
Condition Operational Non-operational
