Ruckus ICX 7450 Switch Hardware Installation Guide 81
Part Number: 53-1003899-09
Data port specifications (Ethernet)
Serial port specifications (pinout - mini-USB)
Model name Port type Number (in module) Description
ICX 7450-24 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, compatible with LR4 or SR4 optical transceivers, or direct
attached copper cable
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
1 GbE 4 (ICX7400-4X1GF) SFP uplink ports, compatible with SX or LX optical transceivers
1 GbE 24 (slot 1) RJ-45 ports
ICX 7450-24P 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, 40 Gbps, compatible with LR4 or SR4 optical transceivers, or
direct attached copper cable
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
1 GbE 4 (ICX7400-4X1GF) SFP uplink ports, compatible with SX or LX optical transceivers
1 GbE 24 (slot 1) RJ-45 ports with PoE support
ICX 7450-32ZP 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, 40 Gbps, compatible with LR4 or SR4 optical transceivers, or
direct attached copper cable.
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
2.5 GbE 8 (slot 1) RJ-45 ports with PoE support
1 GbE 24 (slot 1) RJ-45 ports with PoE support
ICX 7450-48 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, compatible with LR4 or SR4 optical transceivers, or direct
attached copper cable
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
1 GbE 4 (ICX7400-4X1GF) SFP uplink ports, compatible with SX or LX optical transceivers
1 GbE 48 (slot 1) RJ-45 ports
ICX 7450-48P 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, compatible with LR4 or SR4 optical transceivers, or direct
attached copper cable
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR. or USR optical transceivers
1 GbE 4 (ICX7400-4X1GF) SFP uplink ports, compatible with SX or LX optical transceivers
1 GbE 48 (slot 1) RJ-45 ports with PoE support
ICX 7450-48F 40 GbE 2 (ICX7400-1X40GQ) QSFP+ stacking ports, compatible with LR4 or SR4 optical transceivers, or direct
attached copper cable
10 GbE 4 (ICX7400-4X10GC) SFP+ uplink ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
1 GbE 4 (ICX7400-4X1GF) SFP uplink ports, compatible with SX or LX optical transceivers
1 GbE 48 (slot 1) SFP ports, compatible with 100Base-FX IR or LR SFP optic for SMF, 100Base-FX SFP
optic MMF, 1000Base-BXD SFP optic SMF, 1000Base-BXU SFP optic SMF,
1000Base-LHA SFP optic SMF, 1000Base-LX SFP optic SMF, 1000Base-SX SFP
optic MMF, 1000BASE-TX SFP Copper
Pin Signal Description
1 Reserved Not used
2 UART0_RX Debug port (data received by ICX)
3 UART0_TX Console port (data transmitted by ICX)
