Section 2: Basic Operation
19
Supported Sensor Types
The instrument can take measurements using a wide range of
sensors. The sensitivities and types of measurement that can be
taken by each sensor are summarized in the following table.
Note: Velocity, displacement and current sensor types are only
applicable to the vb3000 instrument.
Sensor Type Sensitivity Measurement Types
Accelerometer
mV/g 8.5-2300
Acceleration
Velocity
Displacement
Velocity Sensor
mV/in/s 8.5-2300
mV/mm/s 0.34-90.55
Velocity
Displacement
Sensor
(or prox probe)
mV/mil 8.5-2300
mV/µm 0.34-90.55
Displacement
Current Sensor
mV/amp 0.1-2300 Current
You can define your sensors either in the Ascent software or the
instrument. For information on how to set up a sensor using the
instrument see Specifying Sensor Settings (page
76).
