NBLB2 Service Manual
8
Pointing
Device
- Touch pad with two buttons ( up & down)
Web Cam
- 2.0M pixel CMOS via USB 2.0 interface.
 Auto-focus (ME dimension).
 Face detect function (Compal SW).
 Business card scanner.
 A4 scanner.
I/O Ports
- USB V2.0, x 4, all are with Power USB feature
- RGB; VGA port x 1, 15pins
- Microphone-in x 1
- Headphone-out jack x 1
- DC-in jack x 1
- Mini Card x2
- Media Card Reader(SD/MMC/MS) x 1
- RJ-45 jack x 1
- Kensington lock x 1
- HDMI x 1
- RF-in x 1(option)
- CIR
User keys
- Power Button. x 1
- Magnetic Lid Switch. x 1
- Wireless switch x 1
- Power USB Button x 1
- Smart Key (Program DJ )x 1
- Wow Video. Four modes: Movie, Photo, Office, Nature. x 1
- Wow Audio.
Security
- Fingerprint
TPM 1.2 by Infineon
 Design ready for Windows Vista32 & Windows 7.
- Kensington lock
Controls
- Power button x 1
- Magnetic lid switch control for system standby or suspend
AC adapter
- Universal AC Adapter, 19V DC, 3 pins 240V
90W.
Battery
- Life Cycle: 70% Design Capacity after 300 Cycles in 25 degrees C.
 6-cell Li-On, 18650 type, 4800/5200mAh, CBB-look A30.
Software
- Insyde BIOS
- 2048KB Flash BIOS ROM
- Suspend to RAM/Disk
- No support APM
- USB memory Boot support
- Support SMBIOS 2.4, PCI2.2.
- ACPI 2.0 compliance with Intel Speed-step Support C-State and S3, S4
for mobile CPU
Operating
System
- Windows 7 / Windows Vista 32-bit Premium.
Keyboard
Controller
- ENE KB926 K/B Controller
