NBLB2 Service Manual
54
Offset
Description
BFh
Reserved
12.17.7 Control method for 1st battery pack RAM definition
Offset
Description
C0h
Battery status
Bit7 – Battery type
C1h
Battery Status
Bit0 – Discharging
Bit1 – Charging
Bit2 – Discharging and Now is critical low
Bit3 – Low battery
Bit7 – AC status
C2h-C3h
Remaining Capacity
C4h-C5h
Serial Number
C6h-C7h
Present Voltage
C8h-C9h
Design Voltage
CAh-CBh
Design Capacity
CCh-CDh
Full charge capacity
CEh
Gasgauge
CFh
Battery cycle counter
D0h-D1h
Battery current
D2h-D3h
Battery average current
D4h
System power consumption
D5h
Battery Volt
D6h
Battery Temp
D7h
Battery Average Temp
D8h-D9h
Battery charge current
DAh
Battery current Temp sample counter
DBh
Battery Command index for read battery through SMBus
DCh
Count up to communicate battery
DDh
Count up if battery is arrived overtemp
DEh-DFh
SMBus status
