Compal NBLB2 - External Name Space Definition; Word Registers to Emulate Smart Selector RAM Definition

NBLB2 Service Manual
49
61h
SMBus statue
Bit0-Bit4 – Status
Bit5 - Reserved
Bit6 - ALARM
Bit7 - DONE
62h
SMBus Address
63h
SMBus Command
64h – 83h
SMBus Data
84h
SMBus BCNT
85h
SMBus alarm address
86h
SMBus alarm data 0
87h
SMBus alarm data 1
12.17.4 External name space definition
Offset
Description
94h
EXT_NAMESPACE_INDEX
95h
EXT_NAMESPACE_BANK
96h
EXT_NAMESPACE_DATA
12.17.5 Word registers to Emulate smart selector RAM definition
Offset
Description
9Ah
SEL_STATE0
Bit0 – PRESENT_A(Set if 1st battery present)
Bit1 – PRESENT_B(Set if 2nd battery present)
Bit2 – PRESENT_C(Set if 3rd battery present)
Bit3 – PRESENT_D(Set if 4th battery present)
Bit4 – CHARGE_A(Set if 1st battery be charging)
Bit5 – CHARGE_B(Set if 2nd battery be charging)
Bit6 – CHARGE_C(Set if 3rd battery be charging)
Bit7 – CHARGE_D(Set if 4th battery be charging)
9Bh
SEL_STATE1
Bit0 – PWR_BY_A(Set if system power up by 1st )
Bit1 – PWR_BY_B(Set if system power up by 2nd )
Bit2 – PWR_BY_C(Set if system power up by 3rd )
Bit3 – PWR_BY_D(Set if system power up by 4th )
