Compal NBLB2 - System Components Summary

NBLB2 Service Manual
7
1. System Components Summary
Processor
- Intel Clarsfield Quad Processors, 4 core, Max IMC up to 1333MHz,
- on die, up to 8MB L3 cache.
Core Logic
- Intel Calpella platform:
- Ibex-Peak Platform Controller Hub (PCH), PM55.
System
Memory
- No on board memory
- Support DDR-III 1066/1333 MHz
- Two SODIMM with 1GB/2GB/4GB modules
- Easy upgrade from bottom side for two SODIMM.
- Max. 8GB
Display
- 15.6"W W/LED HD Glare 1366x768(HD)
- 15.6"W HD Glare CMO N156B6-L04 1366x768(HD)
- 15.6"W HD Glare CPT CLAA156WA11A 1366x768(HD)
- 15.6"W HD Glare LG LP156WH2-TLA1 1366x769(HD)
- 15.6"W W/LED Full HD 1920*1080
- 15.6" AU0 LCD_LED_M B156HW01 V3 15.6" FHD
- 15.6" LCD LG _LED_M LP156WF1-TLC1 15.6" FHD G
HDD
- 9.5mm, 2.5" S-ATA HDD
- support with 160/250/320GB ( 5400rpm ) capacity
- support with 160/320GB ( 7200rpm ) capacity
- Easily removable no more than two screws
Optical
Drives
- Fixed 12.7mm height SATA ODD:
- DVD Super-Multi (DVD-RAM/-R/-RW/+R/+RW Super Multi )
 DVD-RAM/-R/-RW writable
 Support Double-Layer Recording is required
High Definition Disc (BD-Multi ROM)
- Blue-Ray/Combo
Video Chip
- GPU On board, ATI Madison Pro 128bits, GDDR3 64Mx16 8pcs
(1024M)
- Hynix-H5TQ1G63BFR-12C or Samsung -K4W1G1646E-HC12
Audio
- Realtek ALC272
- HD Audio
- Microphone-in and headphone-out
- Two speakers
- Two analog & omni microphones, Microphone Array support.
On-board
Comms
- LAN, Atheros AR8131-AL1E, 10/100/1000Mbps.
- Wireless LAN, 802.11a/g/n, Intel Shirley Peak (option).
- 802.11a/b/g/n, Shirley Peak(option).
- Antenna: WiMAX x 2.
- Bluetooth USB type, ver 2.1, Foxconn (Broadcom) (Option).
- Card Reader: Realtek RTS5159.
- TV Tuner: Hybrid TV in mini-Card, YUAN & Askey (option).
Keyboard
- 85/86 keys support with 101/102 key emulation without stick-point.
- Windows key, Application key
- Standard pitch, 300mm travel length.
- Multi-Langue support.
- The plate of K/B for Intel is different with the plate for A30 customers
- The printing of K/B is same for both Intel and A30
