Compal NBLB2 - Special Combine Key for Customer; EC Name Space Configuration; Customer EC Name Space Definition; Project EC Name Space Definition

NBLB2 Service Manual
48
Number lock on
Number lock off
6
O
-
P
1
J
2
K
3
L
+
;
0
M
,
,
.
.
/
/
12.16.5 Special combine key for customer
 Press Fn + L-Ctrl, EC will send R-Ctrl scan code.
 Press Fn + L-Win, EC will send R-Win scan code.
Key
Scan 1 make
Scan 1 break
Scan 2 make
Scan 2 break
L-Ctrl
0x1D
0x9D
0x14
0xF0 0x14
Fn + L-Ctrl
0xE0 0x1D
0xE0 0x9D
0xE0 0x14
0xE0 0xF0 0x14
L-Win
0xE0 0x5B
0xE0 0xDB
0xE0 0x1F
0xE0 0xF0 0x1F
Fn + L-Win
0xE0 0x5C
0xE0 0xDC
0xE0 0x27
0xE0 0xF0 0x27
12.17 EC name space Configuration
12.17.1 Customer EC name space definition
Offset
Description
00h – 07h
Customer EC name space
03h
SmartCharge Ratio
12.17.2 Project EC name space definition
Offset
Description
08h – 0Fh
Project EC name space
12.17.3 SMBus EC interface ACPI RAM definition
Offset
Description
60h
SMBus protocol
