Compal NBLB2 - Chapter 3 Hardware

NBLB2 Service Manual
56
Offset
Description
Bit3 –Stop charge of adapter loading
Bit4 –Stop charge of flash
F4h-F5h
ManufactureDate
F6h-F7h
Charging Voltage
F8h
Battery Cell number
Bit0 –Set Battery is 3 cells
Bit1 –Set Battery is 4 cells
Bit2 –Set Battery is 6 cells
Bit3 –Set Battery is 8 cells
Bit4 –Set Battery is 9 cells
Bit5 –Set Battery is 12 cells
Bit6 –Set battery is 3 series
Bit7 –Set battery is 4 series
F9h-FFh
Reserved
12.17.8 Control method for 2nd battery pack RAM definition
Offset
Description
20h
Battery status
Bit7 – Battery type
21h
Battery Status
Bit0 – Discharging
Bit1 – Charging
Bit2 – Discharging and Now is critical low
Bit3 – Low battery
Bit7 – AC status
22h-23h
Remaining Capacity
24h-25h
Serial Number
26h-27h
Present Voltage
28h-29h
Design Voltage
2Ah-2Bh
Design Capacity
2Ch-2Dh
Full charge capacity
2Eh
Gasgauge
2Fh
Battery cycle counter
30h-31h
Battery current
