NBLB2 Service Manual
53
Offset
Description
.
8 = throttling 100%
Bit6 - THRM_SW (1=SW Throttling active)
Bit7 - THRM_PIN (Throttling status;1=HW Throttling Pin active)
AFh
THROTTLING_SOURCE
Bit0 –TS_THERMAL (1: Throttling for thermal)
Bit1 –TS_BATTCAP (1: Throttling for capacity)
Bit2 –TS_BATTCOMMFAIL (1: Throttling for communication fail)
Bit3 –TS_PWRLOADING (1: Throttling for adaptor power loading protect)
Bit4 –TS_BATTTEMP (1: Throttling for battery over temperature)
Bit5-Bit6 – Reserved
Bit7 –THROTTLING (1: Control HW throttling active)
B0h
CPU_TEMP: CPU current temperature
B1h
CPU_TEMP_LOCAL: CPU local temperature
B2h
SKIN_TEMP90 : SKIN temperature address 90
B3h
OS Shutdown Temp. For system read setting.(VGA)
B4h
VGA_TEMP: VGA temperature
B5h
CPU_DTS: CPU DTS temperature
B6h
NorthBridge temperature
B7h
Reserved
B8h
Reserved
B9h
Lcd brightness value (0x00-0x07)
BAh
Lcd contrast value (0x00-0x1F)
BBh
Device module status
Bit0 - 1=Wirless LAN active, 0=Wirless LAN no active
Bit1 - 1=BlueTooth active, 0=BlueTooth no active
Bit2 - 1=Wirless LAN exist, 0=Wirless LAN no exist
Bit3 - 1=BlueTooth exist, 0=BlueTooth no exist
Bit4 - 1=Kill switch on, 0=Kill switch off
Bit5 - 1=WireLess LAN initial OK
BCh
KbProjectID : Project ID
BDh
CPU_TYPE : CPU type
BEh
Reserved
