NBLB2 Service Manual
52
Offset
Description
Bit1 – ADPOVP (1 = AC_OFF for adaptor improper)
Bit2 – BATTLEARN (1 = AC_OFF for battery at learning mode)
Bit3 – CMD (1 = AC_OFF for Command)
Bit4 – BATTOVP (1 = AC_OFF for battery OVP)
Bit5 –LEAKCURRENT(1 = AC_OFF for Leakage current)
Bit6 –AIRADAPTOR(1 = AC_OFF for air-adaptor)
Bit7 – ACOFF (Control AC_OFF active, 0: enable, 1: disable)
A6h
Reserved
A7h
OS Throttling Temp. For system read setting.
A8h
OS Shutdown Temp. For system read setting.
A9h
Throttling Temp put a temp in for system throttling.
AAh
For Tcontrol temp, sysbios will put Tcontrol temp
ABh
THERMAL_STATUS
Bit0 – MODE (0=Local mode, 1=Remote mode)
Bit1 – FANSPDB0(Fan on/off parameter0)
Bit2 – FANSPDB1(Fan on/off parameter1)
Bit 2 1 ( When control by OS )
0 0 : Fan off
0 1 : Fan on speed 1
1 0 : Fan on speed 2
1 1 : Fan on speed 3
Bit3 – INITOK ( 0:Control by OS 1:Control by EC )
Bit4 – Fan1 Active
Bit5 – Fan2 Active
Bit6 – Fan speed timer init OK
Bit7 –SKINMODE
0=skin address 90
1=skin address 92
ACh
SHUTDOWNTEMP : Shundown temperature
ADh
FAN_STATUS1 : Just for utility (low nibble: Fan's speed step number ;
high nibble: Fan's number )
AEh
THROTTLING_INDEX
Bit 0~5 :Throttling level
0 = No throttling
1 = throttling 12.5%
2 = throttling 25%
