Offset
Description
Bit5 – Blue tooth wake up event(0=off,1=on)
Bit6 – Dock in event(0=off,1=on)
A0h
Throttling index
00: Nothing, 01: Thr 12.5%, 02: Thr 25%,..,08: Thr 100%
Bit6 – (1=SW Throttling active)
Bit7 –(Throttling status;1=HW Throttling Pin active)
A1h
DCID: Customer ID
Bit0 –DockType0, Dock on or not(0=off, 1=on)
Bit1 –DockType1, reserved
Bit4 – OS_undock OK
Bit5 – OS dock OK
Bit6 – Safe Undock OK
Bit7 –DockChange, Ultra Base had changed from docked to undock or undock to dock
(0=no, 1=yes)
A2h
OS Shutdown Temp. For system read setting. (DTS).
A3h
SYS_STATUS: System indicator
Bit2 –Bit0 :OS Type
0 0 0 -WinXP
0 0 1 -Vista
0 1 0 -Linux
0 1 1 -Win7
Bit3 – PCMQ, PCMCIA H/W suspend(0/1=PCMCIA on/suspend )
Bit4 – PCMR, PCMCIA H/W reset (0=disable, 1=enable)
Bit5 –ADP,Ac adapter (0=offline, 1=online)
Bit6 –SYSR6(reserved)
Bit7 –SYSR7(reserved)
A4h
WAKEUP_ENABLE: Enable wake up function
Bit0 –PMEWAKE(PME Wk Enable:0=Disable, 1=Enable)
Bit1 –MDMWAKE (Modem Wk Enable:0=Disable, 1=Enable)
Bit2 - LANWAKE(LAN wakeup enable:0=Disable, 1=Enable)
Bit3 - RTCWAKE (RTC wakeup Enable :0=DIsable, 1=Enable)
Bit4 - WLANWAKE (Wireless LAN wakeup Enable:0=Disable, 1=Enable)
Bit5 - RESERVED
Bit6 - KEYWAKE (Keyboard wakeup enable:0=Disable, 1=Enable)
Bit7 - MOUSWAKE (Mouse wakeup enable:0=Disable, 1=Enable)
A5h
ACOFF_SOURCE: Enable AC_OFF signal
Bit0 – CHARGECURRENT(1 = AC_OFF for when stop charge but have charge current)
