Compaq 1000 Series User Manual

Overview 1-5
LOAD 1 LOAD 2
1
7
6
2
3
4
5
Figure 1-4. Rear panel of T1000h and T1500h
1
Communications port
5
Network Transient Protector
2
10A input circuit breaker
6
Load segment 2
3
IEC-320 power inlet
7
Load segment 1
4
Option slot
1 2
4 356
REMOTE
POWER OFF
12
Figure 1-5. Rear panel of R1500 and R1500j
1
REPO port
4
Load segment 1
2
IEC-320 power inlet
5
Communications port
3
Load segment 2
6
Option slot

Compaq 1000 Series Specifications

General

Brand	Compaq
Model	1000 Series
Category	UPS
Language	English
