Operation 3-9
Placing the UPS in Operate Mode
The 1000 Series UPS may be placed in Operate mode if either of the following
conditions apply:
■ The UPS is powered up and in Standby mode (LED 16 is off)
■ The UPS is powered off; no utility power is available
Press and hold the ON button (
2 ) until the LED 16 (ON LED 1 ) turns green,
indicating that power is available at the UPS output receptacles. The UPS
acknowledges compliance with a short beep.
IMPORTANT: If using battery power (no utility power present), press the ON button and
hold for three seconds. The UPS will conserve battery power by omitting the self-test.
2
3
1
Figure 3-3. Operate mode controls
1
ON LED
2
ON button
3
STANDBY button
