Chapter 7 Power and Signal Distribution
Compaq iPAQ Series of Desktop Personal Computers
Second Edition - February 2001
7-2
7.2.1 POWER SUPPLY ASSEMBLY
The power supply assembly is contained in a single unit that features a selectable input voltage:
90-132 VAC and 180-264 VAC. These systems use a 90-watt power supply. The specifications are
listed in Tables 7-1 and 7-2.
Table 7-1. iPAQ 90-Watt Power Supply Assembly Specifications
Table 7-1.
iPAQ 1.x 90-Watt Power Supply Assembly Specifications (P/N 159447)
Range/
Tolerance
Min. Current
Loading [1]
Max.
Current
Surge
Current [2]
Max.
Ripple
Input Line Voltage:
110 VAC Setting
220 VAC Setting
90 - 132
VAC
180-264
VAC
--
--
--
--
--
--
--
--
Line Frequency 47 - 63 Hz -- -- -- --
Steady State Input (VAC) Current -- -- 3.0 A -- --
+3.3 VDC Output + 5%
0.50 A 6.00 A 6.00 A 50 mV
+5 VDC Output + 5 %
0.70 A 10.0 A 12.0 A 50 mV
+5 AUX Output + 4 %
0.00 A 2.50 A 2.50 A 50 mV
+12 VDC Output + 5 %
0.05 A 1.50 A 3.50 A 120 mV
-12 VDC Output + 10 %
0.00 A 0.30 A 0.30 A 200 mV
NOTES:
[1] Minimum loading requirements must be met at all times to ensure normal operation
and specification compliance.
[2] Surge duration no longer than 10 seconds and +12 tolerance +/- 10%.
Table 7-2. iPAQ 2.0 90-Watt Power Supply Assembly Specifications
Table 7-1.
iPAQ 2.0 90-Watt Power Supply Assembly Specifications (P/N 216922 or 218584 [3])
Range/
Tolerance
Min. Current
Loading [1]
Max.
Current
Surge
Current [2]
Max.
Ripple
Input Line Voltage:
110 VAC Setting
220 VAC Setting
90 - 132
VAC
180-264
VAC
--
--
--
--
--
--
--
--
Line Frequency 47 - 63 Hz -- -- -- --
Steady State Input (VAC) Current -- -- 3.0 A -- --
+3.3 VDC Output + 5%
0.10 A 6.00 A 6.00 A 50 mV
+5 VDC Output + 5 %
1.30 A 14.0 A 15.0 A 50 mV
+5 AUX Output + 5 %
0.00 A 3.00 A 3.00 A 50 mV
+12 VDC Output + 5 %
0.05 A 1.50 A 3.00 A 120 mV
-12 VDC Output + 10 %
0.00 A 0.20 A 0.20 A 200 mV
NOTES:
[1] Minimum loading requirements must be met at all times to ensure normal operation
and specification compliance.
[2] Surge duration no longer than 10 seconds and +12 VDC tolerance + 10%.
[3] P/N 216922 is non-power factor correction (PFC) type. P/N 218584 is PFC type.
All power supply assemblies feature power line surge protection, withstanding brief surges of up to
2000 VAC without damage.
