Chapter 2 System Overview
Compaq iPAQ Series of Desktop Personal Computers
Second Edition – February 2001
2-16
2.4.4 CHIPSET
The chipset is designed to compliment the processor and provide the central point for the system’s
data transactions. The Compaq iPAQ 1.0/1.2 system employs the Intel 810E while the iPAQ 2.0
system uses the Intel 815E chipset.
The chipset is composed of a graphics memory controller hub (GMCH), an I/O controller hub
(ICH), and a firmware hub (FWH). Table 2-3 shows a listing of the functions provided by the two
types of chipsets.
Table 2-3. Chipset Functions
Table 2-3.
Chipset Functions
Chipset Component Function
810E 82810E-DC100 Graphics/Memory
Controller Hub (GMCH)
2D/3D graphics controller
SDRAM controller supporting 2
PC100 DIMMs
66-/100-/133-MHz FSB
PCI bus I/F
82801AA I/O Controller Hub (ICH) LPC bus I/F
SMBus I/F
IDE I/F with UATA/66 support
AC ’97 audio controller
RTC/CMOS
IRQ controller
Power management logic
USB controller (1)
82802 Firmware Controller Hub (FWH) Loaded with Compaq BIOS
Random number generator
815E 82815 Graphics/Memory
Controller Hub (GMCH)
2D/3D graphics controller
SDRAM controller supporting 2
PC100 or PC133 DIMMs
66-/100-/133-MHz FSB
PCI bus I/F
82801BA I/O Controller Hub (ICH2) LPC bus I/F
SMBus I/F
IDE I/F with UATA/100 support
AC ’97 audio controller
RTC/CMOS
IRQ controller
Power management logic
USB controller (2)
Network interface controller
82802 Firmware Controller Hub (FWH) [1] Loaded with Compaq BIOS
Random number generator
NOTE:
[1] Some units may use a non-Intel equivalent component.
