Chapter 5 Input/Output Interfaces
5-2 Compaq iPAQ Series of Desktop Personal Computers
Second Edition – February 2001
5.2.1.1 IDE Configuration Registers
The IDE controller is configured as a PCI device with bus mastering capability. The PCI
configuration registers for the IDE controller function (PCI device #31, function #1) are listed in
Table 5-1.
Table 5–1. IDE PCI Configuration Registers
Table 5-1.
EIDE PCI Configuration Registers (82801, Device 31/Function 1)
PCI Conf.
Addr. Register
Reset
Value
PCI Conf.
Addr. Register
Reset
Value
00-01h Vender ID 8086h 24-2Bh Reserved 0’s
02-03h Device ID [1] 2C, 2Dh Subsystem Vender ID 8086h
04-05h PCI Command 0000h 2E, 2Fh Subsystem ID 2411h
06-07h PCI Status 0280h 30-3Fh Reserved 0’s
08h Revision ID 00h 40-43h Primary IDE Timing 0000h
09h Programming 80h 44h Secondary IDE Timing 00h
0Ah Sub-Class 01h 48h Sync. DMA Control 00h
0Bh Base Class Code 01h 4A-4Bh Sync. DMA Timing 0000h
0Dh Master Latency Timer 0000h 54h EIDE I/O Config.Register 00h
0Eh Header Type 80h F8-FBh Manufacturer’s ID
0F-1Fh Reserved 00h FC-FFh Reserved
20-23h BMIDE Base Address 1h -- -- --
NOTE:
Assume unmarked gaps are reserved and/or not used.
[1] 82801AA ICH = 2411h, 82801BA ICH2 = 244Bh
5.2.1.2 IDE Bus Master Control Registers
The IDE interface can perform PCI bus master operations using the registers listed in Table 5-2.
These registers occupy 16 bytes of variable I/O space set by software and indicated by PCI
configuration register 20h in the previous table.
Table 5–2. IDE Bus Master Control Registers
Table 5-2.
IDE Bus Master Control Registers
I/O Addr.
Offset
Size
(Bytes) Register
Default
Value
00h 1 Bus Master IDE Command (Primary) 00h
02h 1 Bus Master IDE Status (Primary) 00h
04h 4 Bus Master IDE Descriptor Pointer (Pri.) 0000 0000h
08h 1 Bus Master IDE Command (Secondary) 00h
0Ah 2 Bus Master IDE Status (Secondary) 00h
0Ch 4 Bus Master IDE Descriptor Pointer (Sec.) 0000 0000h
NOTE:
Unspecified gaps are reserved, will return indeterminate data, and should not be written to.
