Determining the Network Settings
Determining the Network Settings
If you are not sure what the network information is on a DeviceMaster LT, you can
perform the following procedure.
1. Establish communications with the DeviceMaster L
T using the serial (Page
100) or telnet (Page 101) method.
2. At the RedBoo
t prompt, type ip.
The IP address, subnet mask, and IP gateway values will display.
Note: O
ptionally, you can install PortVision DX on a Windows system on the
network and see the IP information in the Device List pane.
Configuring the Network Settings
Use the following procedure to program the IP address using RedBoot.
1. Establish communications with the DeviceMaster L
T using the serial (Page
100) or telnet (Page 101) method.
2. Enter ip
[addr mask gateway] and press the Enter key to configure the IP
address. Where:
addr = IP
address you want to use
mask = match
es you network subnet mask
gateway = a
ssigned by your network administrator
Make sure that each value is separated
by a space.
3. Verify that RedBoot responds with you
r configured network information or
reiss
ue the command.
4. Type re
set to reset the DeviceMaster LT, if you do not have any other related
RedBoo
t tasks.
RedBoot>dis
Loading disabled
RedBoot> ip
IP: 192.168.250.250
Mask: 255.255.0.0
Gateway: 192.168.50.1
RedBoot>
Default Network
Settings
IPaddress:
192.168.250.250
Subnetmask:
255.255.0.0
Gatewayaddress:
192.168.250.1
RedBoot>dis
Loading disabled
RedBoot> ip
192.168.11.152 255.255.0.0 192.168.0.254
RedBoot>
IP: 192.168.11.
152
Mask: 255.255.00
Gateway: 192.168.0.254
RedBoot> reset
.. Resetting
