SERIES 8000 BOARD LED RELAY FUNCTION
FC SUPPLIES POWER FOR SFC RELAY.
RC LED406 RED, REAR CALL (RC) RELAY INDICATOR. ON WHEN
CALL PRESENT.
RC SUPPLIES POWER FOR SRC RELAY.
LIMIT LED411 RED, FLOOR LIMIT (LIMIT) RELAY INDICATOR. ON
WHEN AT FLOOR AND “S” SIGNAL PRESENT OR WHEN
AT APPROPRIATE TERMINAL LIMIT SWITCH.
LIMIT SWITCHES LOCK SUPPLY.
S LED409 RED, STOP SIGNAL (S) RELAY INDICATOR. ON WHEN
AT CORRECT FLOOR AND STROBE IS PRESENT..
S CLEARS CALL, SWITCHES LOCK SUPPLY.
RLOCK LED412 RED, REAR LOCK SUPPLY. ON WHEN LOCK SUPPLY IS
PRESENT.
SRC LED408 RED, STOP REAR CALL (SRC) RELAY INDICATOR. ON
WHEN AT FLOOR AND CALL HAS BEEN PLACED FOR
SAME.
SRC SWITCHES REAR LOCK SUPPLY.
FLOCK
LED410
RED, FRONT LOCK SUPPLY. ON WHEN LOCK SUPPLY IS
PRESENT.
SFC LED407 RED, STOP FRONT CALL (SFC) RELAY INDICATOR. ON
WHEN AT FLOOR AND CALL HAS BEEN PLACED FOR
SAME.
SFC SWITCHES FRONT LOCK SUPPLY.
DIR SWITCHES DIRECTION OF TRAVEL TO INTERMEDIATE
FLOORS.
FHC LED403 RED, FRONT HALL CALL. ON WHEN BUTTON PUSHED.
GATE/SWING DOOR
CONTROLLER (772003)
DOT LED6 RED, DOOR OPEN TIMER. ON WHILE DOT RELAY IS
ENERGIZED.
SHEET 41 DOT OUTPUTS SIGNAL TO SWING DOOR OPERATOR BOARD
TO SWITCH DAOL. CONTROLS OPEN TIME FOR DOOR.
DOP LED3 RED, DOOR OPEN PILOT. PULSED ON WHEN “DO”
SIGNAL PRESENT AND CALL REGISTERED FOR FLOOR
WHERE CAB IS PARKED.
DOP OUTPUTS MOMENTARY PULSE TO SWING DOOR
OPERATOR TO START DOOR OPEN SEQUENCE.
GOF LED4 RED, GATE OPEN FRONT. ON AS LONG AS SFC IS ON.
GOF SWITCHES OPEN AND CLOSE SIGNAL TO FRONT GATE.
GOR LED5 RED, GATE OPEN REAR. ON AS LONG AS SRC IS ON.
GOR SWITCHES OPEN AND CLOSE SIGNAL TO REAR GATE.
GOP LED2 RED, GATE OPEN PILOT. PULSED WHEN DOORS ARE
CLOSED AND “DO” SIGNAL IS PRESENT.
GOP OUTPUTS PULSE TO START GATE OPEN TIMER.
GOT LED1 RED, GATE OPEN TIMER. ON WHILE GOT RELAY IS
ENERGIZED.
GOT SWITCHES SUPPLY TO OPEN GATE(S). CONTROLS OPEN
TIME FOR GATE.
DOL LED7 RED, DOOR OPEN LIMIT. ON WHEN DOOR IS FULLY
OPEN.
DOL STARTS THE DOOR OPEN TIMER.
DC LED8 RED, DOOR CLOSED. ON WHEN DOOR IS CLOSED.
DC CLEARS THE GATE OPEN TIMER SO THAT GATE
FOLLOWS DOOR.
TRIG2 LED9 RED, TRIGGER2. PULSED FROM “TRIGGER”.
TRIG2 MOMENTARY PULSE, DRIVEN BY TRIGGER, RECYCLES
DOP.
GATE OPERATOR
(773082) SHEET 50
MOTOR
LED1207
RED, UNREGULATED MOTOR SUPPLY IS PRESENT.
