SERIES 8000 BOARD LED RELAY FUNCTION
SHEET 50 27VDC
LED1201
RED, +27VDC REGULATED SUPPLY IS PRESENT.
SHEET 51 12VDC
LED1208
RED, +12VDC REGULATED SUPPLY IS PRESENT.
SHEET 50 RE-OPEN
LED1204
RED, RE-OPEN. PULSED WHEN OVER CURRENT IS
DETECTED.
RE-
OPEN
STOPS CLOSING FUNCTION AND RE-CYCLES GATE
OPEN.
SHEET 50 TIME-OUT
LED1206
RED, TIME-OUT. OFF WHEN GATE HAS NOT HIT
EITHER LIMIT SWITCH IN PRE-DETERMINED TIME. ie.-
GATE STUCK
SHEET 50 TIME-
OUT
SWITCHES MOTOR SUPPLY WHEN GATE MOTOR
STALLED DURING OPEN OR CLOSE.
SHEET 50 GO LED1205 RED, GATE OPEN. ON WHEN “GOF” OR “GOR” SIGNAL
PRESENT.
GO SWITCHES BETWEEN OPEN AND CLOSE FUNCTIONS.
GATE OPERATOR
(773082) SHEET 50
OPEN LED1202 RED, OPEN. ON WHEN GATE IS OPENNING.
OPEN SWITCHES MOTOR SUPPLY FOR OPEN DIRECTION.
SHEET 50 CLOSE
LED1203
RED, CLOSE. ON WHEN GATE IS CLOSING.
CLOSE SWITCHES MOTOR SUPPLY FOR CLOSE DIRECTION.
SWING DOOR
OPERATOR (772004)
SHEET 44
OL LED400 RED, OPEN LIMIT. ON WHEN NOT AT OPEN LIMIT.
OL SWITCHES DAOL AND OPEN FUNCTIONS. ENABLES
DAOL RELAY AND DISABLES OP AND OPA RELAYS.
SHEET 44 CL LED401 RED, CLOSE LIMIT. ON WHEN DOOR NOT AT CLOSED
LIMIT.
CL MAINTAINS LOCK SUPPLY UNTIL DOOR CLOSES.
SHEET 44 ME LED408 RED, MOTOR ENABLE. ON DURING OPENNING CYCLE.
ME SWITCHES SUPPLY FOR THE SWING DOOR MOTOR TO
OP AND DAOL CONTACTS.
SHEET 44 OP LED406 RED, OPEN. ON WHEN “DOT” SIGNAL PRESENT AND
DOOR IS NOT FULLY OPEN.
OP SWITCHES SUPPLY FOR THE SWING DOOR MOTOR TO
ALLOW THE DOOR TO OPEN.
SHEET 44 OPA LED407 RED, AUXILLIARY TO OP RELAY.
OPA MAINTAINS OP RELAY UNTIL DOOR FULLY OPEN.
SHEET 44 DAOL LED405 RED, DOOR AT OPEN LIMIT. ON WHEN DOOR IS AT
OPEN LIMIT.
DAOL SWITCHES SUPPLY FOR THE SWING DOOR MOTOR TO
ALLOW DOOR TO REMAIN OPEN TILL DOT TIMES OUT.
SHEET 44 OC LED402 RED, OVER CURRENT. ON WHEN AN OVER CURRENT
CONDITION HAS BEEN DETECTED, RESETS WHEN
DOOR CLOSED.
OC STOPS THE OPEN CYCLE WHEN DOOR HITS AN
OBSTRUCTION.
SHEET 44 RESET LED404 RED, RESET. ON WHEN “DOT” SIGNAL PRESENT.
RESET CLEARS OVER CURRENT AND ALLOWS DOOR TO RE-
TRY OPEN CYCLE.
SHEET 45 12V LED409 RED, 12VDC REGULATED SUPPLY.
SHEET 44 OC OUTPUT
LED403
YELLOW, OVER CURRENT OUTPUT. FLASHES WHEN
OVER CURRENT DETECTED.
SLIDING DOOR
CONTROLLER
(772019)
DOF LED7 RED, DOOR OPEN FRONT (DOF) RELAY INDICATOR. ON
WHEN DOORS NOT FULLY OPEN AND IN OPENNING
CYCLE.
