SERIES 8000 BOARD LED RELAY FUNCTION
HLCALL
LED5105
RED, HOME LANDING CALL (HLCALL) RELAY
INDICATOR. ON WHEN HOME LANDING CALL IS
PLACED.
HLCAL
L
PLACES CALL TO CUSTOMER SELECTED LANDING
WHEN TIMER TRIPS.
CTIS (772009)
SHEET 12.4
INS LED990 RED, INSPECTION (INS) RELAY INDICATOR. ON WHEN
LIFT IS NOT ON INSPECTION.
INS SWITCHES CONTROL BETWEEN CAR STATION AND
CAR TOP INSPECTION STATION.
IRTX (777087)
IRTX RED, INDICATES IRTX TRANSMITTING.
OPTO READER
(773006)
SHEET 19
1 LED4707 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE BINARY ONE LANE.
2 LED4709 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE BINARY TWO LANE.
4 LED4711 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE BINARY FOUR LANE.
ST LED4713 RED, STROBE (ST) INDICATOR. ON WHEN REFLECTED
SIGNAL PRESENT FROM THE STROBE LANE.
ST DELAYS STROBE SIGNAL AT POWER UP.
LU LED4701 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE LEVEL UP LANE.
DZ LED4703 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE DOOR ZONE LANE.
LD LED4705 RED, INDICATES REFLECTED SIGNAL PRESENT FROM
THE LEVEL DOWN LANE.
VALVE OPERATOR
(772048)
DN LED4 RED, INDICATES PRESENCE OF DOWN SIGNAL.
SHEET 2 UP LED3 RED, INDICATES PRESENCE OF UP SIGNAL.
HS LED5 RED, INDICATES PRESENCE OF HIGH SPEED SIGNAL.
JUNCTION BOARD
(772043)
DM LED1 RED, DOOR MONITOR. INDICATES ALL DOORS CLOSED
WHEN LIT.
SHEET 30 DM SWITCHES DC SIGNAL TO MOTHERBOARD AND POWER
TO DCL CIRCUITRY.
FLOOR1
LED5
RED, INDICATES FIRST FLOOR DOOR CLOSED AND
LOCKED WHEN OFF.
FLOOR2
LED4
RED, INDICATES SECOND FLOOR DOOR CLOSED AND
LOCKED WHEN OFF.
FLOOR3
LED3
RED, INDICATES THIRD FLOOR DOOR CLOSED AND
LOCKED WHEN OFF.
FLOOR4
LED2
RED, INDICATES FOURTH FLOOR DOOR CLOSED AND
LOCKED WHEN OFF.
IRRX (773087)
IRRX INDICATES PRESENCE OF LOCK SUPPLY AND IRTX
SIGNAL.
IRRX SWITCHES INTERMEDIATE FLOOR LOCK SUPPLY.
HIGH VOLTAGE
LIGHTING (772018)
HVL RED, HIGH VOLTAGE LIGHTING (HVL) RELAY
INDICATOR. ON WHEN LIGHTING IS ON.
SHEET 40 HVL USED FOR SWITCHING HIGH VOLTAGES FOR LIGHTING
AND/OR EXHAUST FAN.
AUX (772002)
SHEET 4
SC LED1 GREEN, SAFETY CIRCUIT (SC) RELAY INDICATOR. ON
AS LONG AS SAFETY CIRCUIT IS MADE UP.
SC CONTROLS AVAILABILITY OF LOCK SUPPLY AND +27
SYS DRV.
UDA1 LED2 RED, UP/DOWN AUXILLIARY 1 (UDA1) RELAY
INDICATOR. ON WHEN UDA ON OUTPUT IS ON.
