124
SERIES 8000 BOARD LED RELAY FUNCTION
UDA1 REMOVES AVAILABILITY OF LOCK SUPPLY WHILE
TRAVELLING BETWEEN FLOORS.
IU LED3 RED, IN USE (IU) RELAY INDICATOR. ON WHEN DOORS
OR GATE OPEN OR KEY SWITCH IS ON.
IU WHEN ENABLED, TURNS ON HALL BUTTONS DURING
IN USE. CALL REGISTER WHEN IU DISABLED.
SWITCH INTERFACE
(773116)
1 RED, INDICATES THE BINARY ONE MECHANICAL
SWITCH IS ACTIVATED.
SHEET 65 2 RED, INDICATES THE BINARY TW0 MECHANICAL
SWITCH IS ACTIVATED.
4 RED, INDICATES THE BINARY FOUR MECHANICAL
SWITCH IS ACTIVATED.
ST RED, INDICATES THE STROBE MECHANICAL SWITCH IS
ACTIVATED.
LU RED, INDICATES THE LEVEL UP MECHANICAL SWITCH
IS ACTIVATED.
DZ RED, INDICATES THE DOOR ZONE MECHANICAL
SWITCH IS ACTIVATED.
LD RED, INDICATES THE LEVEL DOWN MECHANICAL
SWITCH IS ACTIVATED.
FIREMAN’S SERVICE
(772026)
EMA LED4 RED, AUXILLIARY TO EM (EMA) RELAY INDICATOR.
ON WHEN AC LIGHTING SUPPLY NOT PRESENT.
SHEET 42 EMA PLACES CALL TO BOTTOM STOP IN EVENT OF POWER
FAILURE WHEN ENABLED (JUMPER SELECTABLE).
UTTA LED3 RED, AUXILLIARY TO UTT (UTTA) RELAY INDICATOR.
ON WHEN UTT (LOW OIL TIMER) IS TRIPPED.
UTTA
WHEN ENABLED, PLACES CALL TO BOTTOM STOP WHEN
LOW OIL TIMER TRIPPED (JUMPER SELECTABLE).
FA1 LED7 RED, FIRE ALARM 1 (FAI)RELAY INDICATOR. ON
WHEN FIRST FLOOR ALARM ACTIVE.
FA1 PLACES CALL TO SECOND FLOOR IN EVENT OF FIRST
FLOOR FIRE ALARM ACTIVE.
FA2 LED6 RED, FIRE ALARM 2 (FA2)RELAY INDICATOR. ON
WHEN SECOND FLOOR ALARM ACTIVE.
FA2 PLACES CALL TO FIRST FLOOR IN EVENT OF SECOND
FLOOR FIRE ALARM ACTIVE.
FS LED8 RED, FIREMAN’S SERVICE (FS) RELAY INDICATOR. ON
WHEN FIRST OR SECOND FLOOR ALARM ACTIVE.
FS PLACES UNIT IN FIREMAN’S SERVICE MODE WHEN
FIRST OR SECOND FLOOR ALARM ACTIVE.
NLD LED2 RED, NORMAL LIMIT DOWN (NLD) RELAY INDICATOR.
ON WHEN AT BOTTOM NORMAL LIMIT.
NLD IN FIREMAN’S SERVICE MODE, ALLOWS DOOR OPEN
AT FIRST STOP ONLY WHEN SECOND FLOOR ALARM
ACTIVE. CLEARS FIRST FLOOR CALL PLACED BY
UTTA OR EMA RELAYS WHEN BOTTOM LIMIT
REACHED.
2S LED5 RED, SECOND STOP (2S) RELAY INDICATOR. ON WHEN
AT SECOND FLOOR STOP.
2S
IN FIREMAN’S SERVICE MODE, ALLOWS DOOR OPEN AT
SECOND STOP ONLY WHEN FIRST FLOOR ALARM ACTIVE.
DZFS LED1 RED, DOOR ZONE FOR FIREMAN’S SERVICE (DZFS)
RELAY INDICATOR. ON WHEN IN DOOR ZONE.
DZFS IN FIREMAN’S SERVICE MODE, IF THE UNIT IS IN
MOTION, STOPS CAB AT NEXT AVAILABLE STOP, THEN
ALLOWS UNIT TO PROCEED TO FIREMAN’S SERVICE
SELECTED STOP.
