126
SERIES 8000
BOARD
JUMPER FUNCTION
OPEN=DISABLE SHORTED=ENABLE SHORT TO OBTAIN LISTED FUNCTION
REGULATOR
(772022)
SHEET 3
J102 TIMED LOCKS. AUTO LIGHT TIMER SWITCHES LOCK SUPPLY OFF WHEN AUTOLIGHT
TIMES OUT. USED IN CONJUNCTION WITH J301(1-2) ON MOTHERBOARD AND J407 ON
FLOOR CARD.
AUX (772002)
SHEET 4
J112 IN-USE INDICATOR SELECTOR. HALL BUTTON LAMPS INDICATE GENERAL IN-USE
CONDITION WHEN ENABLED AND DISPLAYS SPECIFIC CALLS BY FLOOR WHEN
DISABLED.
MOTHERBOARD
(772040)
SHEET 13
J300 (1-2)
OTHER
MANUAL DOORS (AND DOORS BY OTHERS). DOOR CLOSED SIGNAL SELECT.
J300 (2-3)
CPD
CONCORD POWER DOORS. DOOR OPEN LIMIT SIGNAL SELECT.
J301 (1-2)
TL
TIMED LOCK SELECT. AUTO LIGHT TIMER SWITCHES LOCK SUPPLY OFF WHEN
AUTOLIGHT OFF. USED IN CONJUNCTION WITH J102 ON REGULATOR BOARD AND J407
ON FLOOR CARD.
J301 (2-3)
HOR
DOOR CLOSED SELECT. DOOR CLOSED SIGNAL SWITCHES LOCK SUPPLY OFF ONCE
DOOR IS CLOSED. USED IN CONJUNCTION WITH J407 ON FLOOR CARD.
FIREMAN’S
SERVICE
J501 UTT HOME. UNIT FORCED TO BOTTOM STOP WHEN UP TRIP TIMER TRIGGERED.
(772026)
SHEET 42
J502 FIREMAN’S SERVICE BYPASS #1. ALLOWS OPERATION OF UTT HOME AND/OR
EMERGENCY LOWERING OPTIONS AND DISABLES FIREMAN’S SERVICE. USED IN
CONJUNCTION WITH J504.
J503 EMERGENCY POWER LOWERING. UNIT FORCED TO BOTTOM STOP WHEN ON BATTERY
POWER.
J504 FIREMAN’S SERVICE BYPASS #2. ALLOWS OPERATION OF PHOTO-EYES AND/OR DOOR
OPEN BUTTON(S) AND DISABLES FIREMAN’S SERVICE. USED IN CONJUNCTION WITH
J502.
J505 FIREMAN’S SERVICE RECALL FLOOR 1 SELECT. SENDS UNIT TO BOTTOM STOP WHEN
FIREMAN’S SERVICE KEY SWITCHED TO RECALL POSITION.
J506 FIREMAN’S SERVICE RECALL FLOOR 2 SELECT. SENDS UNIT TO SECOND STOP WHEN
FIREMAN’S SERVICE KEY SWITCHED TO RECALL POSITION.
SLIDING DOOR
CONTROLLER
(772019)
SHEET 43
J1 FIREMAN’S SERVICE BYPASS #3. ALLOWS NORMAL OPERATION OF DOOR OPEN TIMER
AND DISABLES FIREMAN’S SERVICE. USED IN CONJUNCTION WITH J502 AND J504 ON
FIREMAN’S SERVICE BD.
J2 (1-2)
DBO
DOORS (SLIDING) BY OTHERS. CONFIGURES CONTROLLER CARD FOR OPERATION
WITH SELCOM SLIDING DOORS ONLY.
J2 (2-3)
CSD
CONCORD SLIDING DOORS. CONFIGURES CONTROLLER FOR OPERATION WITH
CONCORD POWER SLIDING DOORS ONLY.
GATE/SWING DOOR
CONTROLLER
(772003)
SHEET 41
J801 DOL SELECT. USED WITH CONCORD POWER DOORS ONLY. USED IN CONJUNCTION
WITH J300 (2-3) ON MOTHERBOARD. ALWAYS DISABLED WHEN CONTROLLER CARD
USED TO CONTROL GATES ONLY.
SINGLE ENTRANCE
FLOOR (772011)
J401 (1-2)
T
TOP. CONNECTS CALL TO DOWN PILOT.
SHEET 10 J401 (2-3)
B
BOTTOM. CONNECTS CALL TO UP PILOT.
J402
SFCC
SECURE FRONT CAR CALL. ENABLES FRONT CAR CALL. CAN BE USED FOR KEYED
ACCESS.
J404 (1-2)
KWIK
KWIK. CONTINUOUSLY MAINTAINS LOCK SUPPLY WHILE AT FLOOR.
J404 (2-3)
CPD
CONCORD POWER DOORS. MAINTAINS LOCK SUPPLY TO HALL STATION ONLY WHILE
DOOR IS NOT CLOSED.
J407
TL
TIMED LOCKS. MAINTAINS LOCK SUPPLY WHILE EITHER AUTO LIGHT IS ON OR WHILE
DOOR OPEN BUTTON IS DEPRESSED DEPENDING ON STATUS OF J301 ON
MOTHERBOARD.
J409
INT
INTERMEDIATE LIMIT. STOP SIGNAL TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
J410 (1-2)
B
BOTTOM. NORMAL LIMIT DOWN TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
J410 (2-3)
T
TOP. NORMAL LIMIT UP TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
J411 (1-2)
F
FRONT. OUTPUTS SIGNAL FOR OPENING POWER GATES AND/OR DOORS AT FRONT OF
CAB. USED WITH UNITS HAVING ONLY ONE ENTRANCE PER FLOOR.
J411 (2-3)
R
REAR. OUTPUTS SIGNAL FOR OPENING POWER GATES AND/OR DOORS AT REAR (OR
SIDE) OF CAB. USED WITH UNITS HAVING ONLY ONE ENTRANCE PER FLOOR.
DUAL ENTRANCE
FLOOR (772023)
J401 (1-2)
T
TOP. CONNECTS CALL TO DOWN PILOT.
SHEET 9 J401 (2-3)
B
BOTTOM. CONNECTS CALL TO UP PILOT.
