127
SERIES 8000
BOARD
JUMPER FUNCTION
OPEN=DISABLE SHORTED=ENABLE SHORT TO OBTAIN LISTED FUNCTION
J402
SFCC
SECURE FRONT CAR CALL. ENABLES FRONT CAR CALL. CAN BE USED FOR KEYED
ACCESS.
J403
SRCC
SECURE REAR CAR CALL. ENABLES REAR CAR CALL. CAN BE USED FOR KEYED
ACCESS.
J404 (1-2)
KWIK
KWIK. CONTINUOUSLY MAINTAINS LOCK SUPPLY TO HALL STATION WHILE AT FLOOR.
J404 (2-3)
CPD
CONCORD POWER DOORS. MAINTAINS LOCK SUPPLY TO HALL STATION ONLY WHILE
DOOR IS NOT CLOSED.
J405 FRONT SELECT. ENABLES USE OF SFC RELAY. CAN BE USED FOR KEYED ACCESS FOR
LOCKOUT.
J406 DUAL ENTRANCE. TIES SFC AND SRC RELAYS TOGETHER TO OPERATE DOORS AT
SAME FLOOR SIMULTANEOUSLY.
J407
TL
TIMED LOCKS. MAINTAINS LOCK SUPPLY TO HALL STATION WHILE EITHER AUTO LIGHT
IS ON OR WHILE DOOR OPEN BUTTON IS DEPRESSED DEPENDING ON STATUS OF J301
ON MOTHERBOARD.
J408 REAR SELECT. ENABLES USE OF SRC RELAY. CAN BE USED FOR KEYED ACCESS FOR
LOCKOUT.
J409
INT
INTERMEDIATE LIMIT. STOP SIGNAL TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
J410 (1-2)
B
BOTTOM. NORMAL LIMIT DOWN TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
J410 (2-3)
T
TOP. NORMAL LIMIT UP TURNS ON LIMIT RELAY TO ENABLE LOCK SUPPLY.
TRAVELLING
LANTERN/HOME
LANDING
J5101
1S
STOP#1 (BOTTOM). SELECTS THE BOTTOM STOP TO HOME TO WHEN UNIT IS NOT
BEING USED. USED IN CONJUNCTION WITH CALL1 BELOW.
(772051)
SHEET 63
J5102
2S
STOP#2. SELECTS THE SECOND FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL2 BELOW.
J5103
3S
STOP#3. SELECTS THE THIRD FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL3 BELOW.
J5104
4S
STOP#4. SELECTS THE FOURTH FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL4 BELOW.
J5105
5S
STOP#5. SELECTS THE FIFTH FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL5 BELOW.
J5106
6S
STOP#6. SELECTS THE SIXTH FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL6 BELOW.
J5107
7S
STOP#7. SELECTS THE SEVENTH FLOOR STOP TO HOME TO WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH CALL7 BELOW.
J5111
CALL1
CALL#1 (BOTTOM). PLACES CALL TO THE BOTTOM STOP WHEN UNIT IS NOT BEING
USED. USED IN CONJUNCTION WITH 1S ABOVE.
J5112
CALL2
CALL#2. PLACES CALL TO THE SECOND FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 2S ABOVE.
J5113
CALL3
CALL #3. PLACES CALL TO THE THIRD FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 3S ABOVE.
J5114
CALL4
CALL #4. PLACES CALL TO THE FOURTH FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 4S ABOVE.
J5115
CALL5
CALL #5. PLACES CALL TO THE FIFTH FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 5S ABOVE.
J5116
CALL6
CALL #6. PLACES CALL TO THE SIXTH FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 6S ABOVE.
J5117
CALL7
CALL #7. PLACES CALL TO THE SEVENTH FLOOR STOP WHEN UNIT IS NOT BEING USED.
USED IN CONJUNCTION WITH 7S ABOVE.
OUTPUT (772005)
SHEET 11
J901 GATE - CALL DISABLE. GATE DISABLES ALL CALLS WHILE GATE IS OPEN. USED WITH
MANUAL GATES TO KEEP UNIT FROM LOCKING OUT PASSENGERS WHEN CALL PLACED
WITH DOOR CLOSED AND GATE LEFT OPEN.
J902 1CO. DISABLES CALLS ONCE ONE CALL IS REGISTERED. USED WITH AUTOMATIC UNITS
ONLY.
J903 GAL. ALLOWS DZ TO BYPASS DCL UNTIL MECHANICAL GAL LOCKS ARE MADE.
JUNCTION BOARD
(772043)
SHEET 30
J4301 (1-2) AUTO SWING DOORS. DOOR OPEN LIMIT SELECT. USED IN CONJUNCTION WITH J300(2-
3) ON MOTHERBOARD.
J4301 (2-3) OTHER DOORS. DOOR CLOSED LIMIT SELECT. USED IN CONJUNCTION WITH J300(1-2)
ON MOTHERBOARD.
J4302 DM BYPASS. USED ONLY WITH CONCORD SWING DOORS. BY-PASSES DOOR MONITOR
CONTACTS.
J4303 (1-2) FLOOR 1 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN FIRST FLOOR DOOR IS
OPEN.
J4303 (2-3) FLOOR 1 PRO LOCK WITH MANUAL DOORS. SWITCHES DOOR MONITOR OFF WHEN
FIRST FLOOR DOOR IS OPEN. USED IN CONJUNCTION WITH J4304.
