128
SERIES 8000
BOARD
JUMPER FUNCTION
OPEN=DISABLE SHORTED=ENABLE SHORT TO OBTAIN LISTED FUNCTION
J4304 FLOOR 1 PRO LOCK WITH MANUAL DOORS. USED IN CONJUNCTION WITH J4303.
J4305 (1-2) FLOOR 2 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN SECOND FLOOR DOOR IS
OPEN.
J4305 (2-3) FLOOR 2 PRO LOCK WITH MANUAL DOORS. SWITCHES DOOR MONITOR OFF WHEN
FIRST FLOOR DOOR IS OPEN. USED IN CONJUNCTION WITH J4306.
J4306 FLOOR 2 PRO LOCK WITH MANUAL DOORS. USED IN CONJUNCTION WITH J4305.
J4307 (1-2) FLOOR 3 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN THIRD FLOOR DOOR IS
OPEN.
J4307 (2-3) FLOOR 3 PRO LOCK WITH MANUAL DOORS. SWITCHES DOOR MONITOR OFF WHEN
FIRST FLOOR DOOR IS OPEN. USED IN CONJUNCTION WITH J4308.
J4308 FLOOR 3 PRO LOCK WITH MANUAL DOORS. USED IN CONJUNCTION WITH J4307.
J4309 (1-2) FLOOR 4 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN FOURTH FLOOR DOOR IS
OPEN.
J4309 (2-3) FLOOR 4 PRO LOCK WITH MANUAL DOORS. SWITCHES DOOR MONITOR OFF WHEN
FIRST FLOOR DOOR IS OPEN. USED IN CONJUNCTION WITH J4310.
J4310 FLOOR 4 PRO LOCK WITH MANUAL DOORS. USED IN CONJUNCTION WITH J4309.
JUNCTION BOARD
5/6
J4401 (1-2) FLOOR 5 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN FIFTH FLOOR DOOR IS
OPEN.
(772044) J4401 (2-3) FLOOR 5 PRO LOCK WITH MANUAL DOORS.
SHEET 30.5 J4402 FLOOR 5 PRO LOCK WITH MANUAL DOORS.
J4403 (1-2) FLOOR 6 KWIK LOCK. SWITCHES DOOR MONITOR OFF WHEN SIXTH FLOOR DOOR IS
OPEN.
J4403 (2-3) FLOOR 6 PRO LOCK WITH MANUAL DOORS.
J4404 FLOOR 6 PRO LOCK WITH MANUAL DOORS.
GATE OPERATOR
(773082)
PARK
OPEN
PARK OPEN. LIFT PARKS WITH GATE OPEN UNTIL A CALL IS REGISTERED.
SHEET 50 PARK
CLOSED
PARK CLOSED. LIFT PARKS WITH GATE CLOSED AFTER DOOR IS CLOSED.
IN-DOOR BUTTON
(773024)
SHEET 31
J500 (1-2)
ES/GAL
ES/GAL. ALLOWS USE WITH EITHER ELECTRIC STRIKES OR GAL LOCKS.
J500 (2-3)
BOX
BOX. ALLOWS USE ONLY WITH SMART KWIK LOCKS.
CAR BUTTON BD.
(772042)
SHEETS 70-71
J4200 (1-2)
OTHERS
OTHERS. CONFIGURES CAR BUTTON BOARD FOR USE WITH ALL STANDARD UNITS NOT
REQUIRING FIREMAN’S SERVICE.
J4200 (2-3)
FS
FIREMAN’S SERVICE. CONFIGURES CAR BUTTON BOARD FOR CORRECT OPERATION
OF FIREMAN’S SERVICE.
RDC (773136)
SHEET 12.3
TEST
JUMPER
TEST JUMPER. HOLDING LOCATION FOR JUMPER USED TO TEST RDC FUNCTIONS.
ALWAYS RETURN JUMPER HERE FOR FUTURE RETESTING.
J901 LEVEL UP CONTACTS. MOMENTARILY JUMP OUT AWAY FROM FLOOR TO TEST RDC
FUNCTION. NEVER STORE JUMPER HERE.
J902 LEVEL DOWN CONTACTS. MOMENTARILY JUMP OUT AWAY FROM FLOOR TO TEST RDC
FUNCTION. NEVER STORE JUMPER HERE.
J903 DOOR ZONE CONTACTS. MOMENTARILY JUMP OUT AWAY FROM FLOOR TO TEST RDC
FUNCTION. NEVER STORE JUMPER HERE.
J904 DOORS CLOSED AND LOCKED CONTACTS. MOMENTARILY JUMP OUT WHILE DOOR IS
OPEN TO TEST RDC FUNCTION. NEVER STORE JUMPER HERE.
J905 DOORS CLOSED AND LOCKED 1 CONTACTS. MOMENTARILY JUMP OUT WHILE DOOR IS
OPEN TO TEST RDC FUNCTION. NEVER STORE JUMPER HERE.
J906 POTENTIAL CONTACTS. MOMENTARILY JUMP OUT WHILE DOOR IS OPEN TO TEST RDC
FUNCTION. NEVER STORE JUMPER HERE.
J907 UP PILOT 2 CONTACTS. MOMENTARILY JUMP OUT WHILE DOOR IS OPEN TO TEST RDC
FUNCTION. NEVER STORE JUMPER HERE.
J908 DOWN PILOT 1 CONTACTS. MOMENTARILY JUMP OUT WHILE DOOR IS OPEN TO TEST
RDC FUNCTION. NEVER STORE JUMPER HERE.
SMART KWIK LOCK
(772008)
J800 (1-2)
KWIK
KWIK. CONFIGURES LOCK PCB FOR USE WITH SERIES 8000 UNITS ONLY.
SHEET 33 J800 (2-3)
PAL
PAL. CONFIGURES LOCK PCB FOR USE WITH SERIES 1000 UNITS ONLY.
