J701 J702 J703 J704 J705 J706 J707 TIMER BD. (772017) JUMPER FUNCTIONS
SCHEMATIC SHEETS 7-8
o---o o o o o o o o o o o o o J701. CAR KEY SWITCH TURNS ON ET/NI AND INUSE.
o o o---o o o o o o o o o o o J702. CAR KEY SWITCH TURNS OFF CAR BUTTON CONTROL WHEN
KEY SWITCH IS OFF.
o o o o o---o o o o o o o o o J703. MAINTAINS CALL ENABLE HIGH.
o o o o o o o---o o o o o o o J704. HALL BUTTON COMMON HIGH WHEN KEY SWITCH IS ON AND
ET/NI IS OFF.
o o o o o o o o o---o o o o o J705. HBC HIGH WHEN ET/NI IS OFF. KEY SWITCH HAS NO DIRECT
CONTROL OVER HALL BUTTONS.
o o o o o o o o o o o---o o o J706. TURNS ON ET/NI USING SIGNALS FROM CAR CALLS OR
INDEPENDENT SERVICE OPTION.
o o o o o o o o o o o o o---o J707. TURNS ON ET/NI WHEN A DOOR IS OPEN. USED WHITH ALL
UNITS EXCEPT HORIZONS.
o o o---o o---o o o o---o o o o---o BASIC RESIDENTIAL WITHOUT CAR KEY SWITCH. CAR KEY SWITCH
HEADER JUMPED (CAR KEY SWITCH ON) ENABLES ALL FUNCTIONS.
CAR HAS PRIORITY OVER HALLS.
o o o---o o---o o o o---o o o o---o BASIC RESIDENTIAL WITH CAR KEY SWITCH. CAR STATION
CONTROLS ENABLED ONLY WHEN CAR KEY SWITCH IS ON. CAR HAS
PRIORITY OVER HALLS.
o o o---o o---o o o o---o o---o o---o COMMERCIAL WITHOUT CAR KEY SWITCH. CAR KEY SWITCH
HEADER JUMPED (CAR KEY SWITCH ON) ENABLES ALL FUNCTIONS.
CAR HAS PRIORITY OVER HALLS.
o---o o---o o---o o o o---o o o o---o COMMERCIAL WITH CAR KEY SWITCH. CAR KEY SWITCH TOGGLES
CONTROL BETWEEN CAR (KEY ON) AND HALLS (KEY OFF).
o o o---o o o o o o---o o o o---o MASTER IN-CAR KEY SWITCH. ALL FUNCTIONS DISABLED EXCEPT
CURRENT FLOOR HALL ACCESS WHEN KEY SWITCH OFF. ALL
FUNCTIONS ENABLED WHEN KEY SWITCH ON.
o---o o o o o o---o o o o o o---o MASTER REMOTE KEY SWITCH. MASTER KEY SWITCH DISABLES ALL
CONTROLS WHEN KEY SWITCH IS OFF. ALL FUNCTIONS ENABLED
WHEN CAR KEY SWITCH IS ON.
o o o---o o---o o o o---o o---o o o COMMERCIAL HORIZON WITHOUT CAR KEY SWITCH. CAR KEY
SWITCH HEADER JUMPED (CAR KEY SWITCH ON) ENABLES ALL
FUNCTIONS. CAR HAS PRIORITY OVER HALLS.
o---o o---o o---o o o o---o o o o o COMMERCIAL HORIZON WITH CAR KEY SWITCH. CAR KEY SWITCH
TOGGLES CONTROL BETWEEN CAR (KEY ON) AND HALLS (KEY OFF).
o o o---o o o o o o---o o o o o HORIZON MASTER IN-CAR KEY SWITCH. ALL FUNCTIONS DISABLED
EXCEPT CURRENT FLOOR HALL ACCESS WHEN KEY SWITCH OFF.
ALL FUNCTIONS ENABLED WHEN KEY SWITCH ON.
o---o o o o o o---o o o o o o o HORIZON MASTER REMOTE KEY SWITCH. MASTER KEY SWITCH
DISABLES ALL CONTROLS WHEN KEY SWITCH IS OFF. ALL
FUNCTIONS ENABLED WHEN CAR KEY SWITCH IS ON.
