3 SPECIFICATIONS CONEL FLOW
RAIN-CHAMPION
3.1 HYDRAULIC DATA CONEL FLOW RAIN-CHAMPION
Property Conel Flow Rain-Champion
Max head (Hmax.) 42.5 m
Max. Förderström (Qmax.) 4.8 m3/h
Max plant height 30 m
Switch-on pressure Pump switching
machine
1.5bar - 3.5bar adjustable
Min. ow rate >2 liters / min.
3.2 ELECTRICAL DATA CONEL FLOW RAIN-CHAMPION
Property Conel Flow Rain-Champion
Voltage 230V / 50Hz
Rated current 3.9A
Engine power P1 880W
Engine power P2 550w
Power cord Protective contact plug
Length 1.5 m
3.3 OPERATING DATA CONEL FLOW RAIN-CHAMPION
Property Conel Flow Rain-Champion
Noise level 58db
Insulating material class motor Class F
Temperature conveying medium +15°C - +40°C
Drinking water connection DN 17 / max. 4 bar
Max. plant pressure 6 bar
Max ow rate in RW operation 4.9m3/h
Max ow rate in DW operation 4.0m3/h at 4 bar
Max suction depth 8m
Quality conveying medium Clean, free of solids or grinding particles, non-viscous, non-
aggressive, non-crystallized and chemically neutral, similar to
the properties of water
Manual switching mode Yes
Pump switching machine With pressure-dependent switch-on and ow-dependent
shutdown
Class IP 42
Energy consumption Standby approx. 1.4 W
