12.08 Variable selector 1 source 1
12.28 Variable selector 2 source 1
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on reset
12.09 Variable selector 1 source 2
12.29 Variable selector 2 source 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on reset
12.10 Variable selector 1 mode
12.30 Variable selector 2 mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 11
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
12.11 Variable selector 1 destination
12.31 Variable selector 2 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on reset
12.12 Variable selector 1 output
12.32 Variable selector 2 output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range ±100.00 %
Update rate 4ms x number of menu 9 or 12 functions active write
12.13 Variable selector 1 source 1 scaling
12.33 Variable selector 2 source 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 4ms x number of menu 9 or 12 functions active read
