changed back to an earlier version defaults should be loaded after
the change.
3.3 Loading defaults
When defaults are loaded the user save parameters are automatically
saved to the drive EEPROM in all modes. Standard defaults are loaded
by setting 1233 in Pr x.00 performing a drive reset.
The following differences from standard defaults are available when
different values are set in Pr x.00.
US Default Differences (Pr x.00 = 1244 and perform a drive reset)
3.4 SMARTCARD transfers
Drive parameters, set-up macros and internal ladder programs can be
transferred to/from SMARTCARDs. See Pr 11.36 to Pr 11.40.
3.5 Electronic nameplate transfers
Some encoders using Stegmann Hiperface or EnDat comms can hold
motor data. The data can be transferred to/from the encoder by writing
110zy to parameter x.00 and resetting the drive where z is 0 for the drive
or 1, 2 or 3 for Solutions Module slots 1, 2 or 3 respectively. See Chapter
7 Electronic nameplate on page 216 for details.
3.6 Display non-default values or
destination parameters
If a value of 12000 is written to Pr x.00, then only parameters that are
different from the last defaults loaded and Pr x.00 are displayed. If a
value of 12001 is written to Pr x.00, then only destination parameters are
displayed. This function is provided to aid locating destination clashes if
a dESt trip occurs.
Pr Description Default Voltage rating
2.08 Standard ramp volts 775V 400V
5.09 Rated voltage 460V 400V
21.09 M2 Rated voltage 460V 400V
