5.12 Menu 10: Status and trips

Indicates the drive is not in the trip state. If Pr 10.36 is one and auto-reset is being used, this bit is not cleared until all auto-resets have been

attempted and the next trip occurs. The control board LED reflects the state of this parameter: LED on continuously = 1, LED flashing = 0.

Indicates that the drive inverter is active.

Indicates that the absolute value of speed feedback (Pr 3.02) is at or below the zero speed threshold defined by Pr 3.05.

In bipolar mode (Pr 1.10 = 1) this parameter is the same as zero speed (Pr 10.03). In unipolar mode this parameter is set if the absolute value of the

speed feedback (Pr 3.02) is at or below (minimum speed + 5rpm). Minimum speed is defined by Pr 1.07. The parameter is only set if the drive is

running.

These flags are set by the speed detector in menu 3.

See Pr 3.06, Pr 3.07 on page 45 and Pr 3.09 on page 46.

Indicates that the modulus of the active current is greater or equal to the rated active current as defined in menu 4.

10.01 Drive ok

Coding
