Specifies the minor revision number of the operating system of the Motion Processor. Use in conjunction with Pr 17.02 to form the complete version
number.
5.18.3 Digitax ST EZMotion
This parameter shows the status of digital output 1 on the Motion Processor. A value of 1 indicates that the output is active. A value of 0 indicates that
the output is inactive. This equates Pin 6 on the EZMotion I/O Connector.
This parameter shows the status of digital output 2 on the Motion Processor. A value of 1 indicates that the output is active. A value of 0 indicates that
the output is inactive. This equates Pin 7 on the EZMotion I/O Connector.
This parameter shows the status of digital input 1 on the Motion Processor. A value of 1 indicates that the input is active. A value of 0 indicates that
the input is inactive. This equates Pin 2 on the EZMotion I/O Connector.
This parameter shows the status of digital input 2 on the Motion Processor. A value of 1 indicates that the input is active. A value of 0 indicates that
the input is inactive. This equates Pin 3 on the EZMotion I/O Connector.
17.51 Motion Processor software sub-version
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 99
Update rate 4ms write
17.01 Motion Processor ID
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 599
Update rate Write on power-up
17.02 Motion Processor software version
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111 1
Range 00.00 to 99.99
Update rate Write on power-up
17.13 EZOutput 1 Status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Trajectory update rate (user configured)
17.14 EZOutput 2 Status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Trajectory update rate (user configured)
17.17 EZInput 1 Status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Trajectory update rate (user configured)
17.18 EZInput 2 Status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Trajectory update rate (user configured)
