5.18 Menu 17: Motion Processors
Menu 17 parameter functions are dependant on the Digitax ST variant.
5.18.1 Digitax ST Base
Menu 17 not available.
5.18.2 Digitax ST Indexer and Digitax ST Plus
Provides the run status of the user DPL program in the Motion Processor. The following values are defined:
Displays the free CPU resource as a percentage of the current background execution time calculated over 200ms.
Defines the address of this node for ANSI and Modbus communications protocols. For the ANSI protocol the address range is 11 to 99 where the first
digit is the group address and the second digit is the unit number. Both digits must be in the range of 1-9. Zero is not permitted since it is used by the
master for addressing groups of nodes. This parameter has no effect if the EIA-RS485 mode is 25 (CTSync) or 26 (CTSync).
17.01 Motion Processor ID
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 599
Update rate 4ms write
17.02 Motion Processor software version
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0.00 to 99.99
Update rate 4ms write
17.03 DPL program status
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range None (0), Stop (1), Run (2), Trip (3)
Update rate 4ms write
Display Value Description
nonE 0 No DPL program present
StoP 1 DPL program is stopped
run 2 DPL program is running
triP 3
Run-time error. ERROR task running or DPL
program stopped
17.04 Available system resource
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 100
Update rate 4ms write
17.05 RS485 address
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 255
Default 11
Update rate 4ms write
